| 项目 | Item | 单位 | Z360 | ||
| 注射装置 | INJECTION UNIT | A | B | C | |
| 螺杆直径 | Screw diameter | mm | 65 | 70 | 75 |
| 理论注射容量 | Shot volume(theoretical) | cm3 | 1112 | 1289 | 1480 |
| 注射重量 | Injection weight(ps) | g | 1012 | 1175 | 1349 |
| 注射速率 | Injection rate | g/s | 337 | 368 | 422 |
| 注射压力 | Injection pressure | Mpa | 195 | 170 | 148 |
| 螺杆转速 | Screw speed | rpm | 190 | ||
| 锁模装置 | CLAMPING UNIT | ||||
| 锁模力 | Clamping force | kN | 3600 | ||
| 移模行程 | Open stroke | mm | 660 | ||
| 拉杆间距(宽×高) | Space between tie bars(W×H) | mm | 670×670 | ||
| 最大模厚 | Max.Mold height | mm | 720 | ||
| 最小模厚 | Min.Mold height | mm | 250 | ||
| 顶出行程 | Ejector stroke | mm | 160 | ||
| 顶出力 | Ejector stroke | kN | 70 | ||
| 其他 | OTHERS | ||||
| 最大油泵压力 | Max Pump pressure | kW | 16 | ||
| 油泵电机功率 | Pump motor power | kW | 37 | ||
| 电热功率 | Heating power | kW | 24.6 | ||
| 外形尺寸(长×宽×高) | Machine dimension(L×W×H) | m | 7.21×1.90×2.34 | ||
| 油箱容积 | Olitank cubage | L | 620 | ||
| 机器重量 | Machine weight | t | 12.5 | ||
