| 项目 | Item | 单位 | Z310 | ||
| 注射装置 | INJECTION UNIT | A | B | C | |
| 螺杆直径 | Screw diameter | mm | 55 | 60 | 65 |
| 理论注射容量 | Shot volume(theoretical) | cm3 | 700 | 834 | 978 |
| 注射重量 | Injection weight(ps) | g | 637 | 759 | 890 |
| 注射速率 | Injection rate | g/s | 223.5 | 266 | 312.2 |
| 注射压力 | Injection pressure | Mpa | 200 | 168 | 143 |
| 螺杆转速 | Screw speed | rpm | 180 | ||
| 锁模装置 | CLAMPING UNIT | ||||
| 锁模力 | Clamping force | kN | 3100 | ||
| 移模行程 | Open stroke | mm | 590 | ||
| 拉杆间距(宽×高) | Space between tie bars(W×H) | mm | 620×620 | ||
| 最大模厚 | Max.Mold height | mm | 630 | ||
| 最小模厚 | Min.Mold height | mm | 200 | ||
| 顶出行程 | Ejector stroke | mm | 150 | ||
| 顶出力 | Ejector stroke | kN | 70 | ||
| 其他 | OTHERS | ||||
| 最大油泵压力 | Max Pump pressure | kW | 16 | ||
| 油泵电机功率 | Pump motor power | kW | 30 | ||
| 电热功率 | Heating power | kW | 18.3 | ||
| 外形尺寸(长×宽×高) | Machine dimension(L×W×H) | m | 5.98×1.66×2.37 | ||
| 油箱容积 | Olitank cubage | L | 385 | ||
| 机器重量 | Machine weight | t | 9 | ||
