| 项目 | Item | 单位 | Z1100 | |||
| 注射装置 | INJECTION UNIT | A | B | C | D | |
| 螺杆直径 | Screw diameter | mm | 100 | 110 | 120 | 130 |
| 理论注射容量 | Shot volume(theoretical) | cm3 | 4712 | 5702 | 6899 | 8348 |
| 注射重量 | Injection weight(ps) | g | 4288 | 5189 | 6278 | 7597 |
| 注射速率 | Injection rate | g/s | 660 | 798 | 966 | 1169 |
| 注射压力 | Injection pressure | Mpa | 207 | 171 | 144 | 123 |
| 螺杆转速 | Screw speed | rpm | 100 | |||
| 锁模装置 | CLAMPING UNIT | |||||
| 锁模力 | Clamping force | kN | 11000 | |||
| 移模行程 | Open stroke | mm | 1250 | |||
| 拉杆间距(宽×高) | Space between tie bars(W×H) | mm | 1170×1170 | |||
| 最大模厚 | Max.Mold height | mm | 1220 | |||
| 最小模厚 | Min.Mold height | mm | 500 | |||
| 顶出行程 | Ejector stroke | mm | 325 | |||
| 顶出力 | Ejector stroke | kN | 245 | |||
| 其他 | OTHERS | |||||
| 最大油泵压力 | Max Pump pressure | kW | 16 | |||
| 油泵电机功率 | Pump motor power | kW | 37+55 | |||
| 电热功率 | Heating power | kW | 60.9 | 67 | 73 | 75 |
| 外形尺寸(长×宽×高) | Machine dimension(L×W×H) | m | 11.5×2.6×2.85 | |||
| 油箱容积 | Olitank cubage | L | 1600 | |||
| 机器重量 | Machine weight | t | 50 | |||
