| 项目 | Item | 单位 | Z780 | ||
| 注射装置 | INJECTION UNIT | A | B | C | |
| 螺杆直径 | Screw diameter | mm | 90 | 100 | 110 |
| 理论注射容量 | Shot volume(theoretical) | cm3 | 3147 | 3886 | 4702 |
| 注射重量 | Injection weight(ps) | g | 2864 | 3536 | 4279 |
| 注射速率 | Injection rate | g/s | 565 | 697 | 843 |
| 注射压力 | Injection pressure | Mpa | 215 | 174 | 144 |
| 螺杆转速 | Screw speed | rpm | 97 | ||
| 锁模装置 | CLAMPING UNIT | ||||
| 锁模力 | Clamping force | kN | 9800 | ||
| 移模行程 | Open stroke | mm | 1120 | ||
| 拉杆间距(宽×高) | Space between tie bars(W×H) | mm | 1080*1080 | ||
| 最大模厚 | Max.Mold height | mm | 1080 | ||
| 最小模厚 | Min.Mold height | mm | 450 | ||
| 顶出行程 | Ejector stroke | mm | 325 | ||
| 顶出力 | Ejector stroke | kN | 246 | ||
| 其他 | OTHERS | ||||
| 最大油泵压力 | Max Pump pressure | kW | 16 | ||
| 油泵电机功率 | Pump motor power | kW | 22+55 | ||
| 电热功率 | Heating power | kW | 58 | ||
| 外形尺寸(长×宽×高) | Machine dimension(L×W×H) | m | 11.43×2.40×3.14 | ||
| 油箱容积 | Olitank cubage | L | 1200 | ||
| 机器重量 | Machine weight | t | 43 | ||
