| 项目 | Item | 单位 | Z780 | |||
| 注射装置 | INJECTION UNIT | A | B | C | D | |
| 螺杆直径 | Screw diameter | mm | 90 | 95 | 105 | 110 |
| 理论注射容量 | Shot volume(theoretical) | cm3 | 2990 | 3331 | 4070 | 4466 |
| 注射重量 | Injection weight(ps) | g | 2721 | 3032 | 3703 | 4064 |
| 注射速率 | Injection rate | g/s | 574 | 640 | 781 | 858 |
| 注射压力 | Injection pressure | Mpa | 195 | 175 | 143 | 130 |
| 螺杆转速 | Screw speed | rpm | 100 | |||
| 锁模装置 | CLAMPING UNIT | |||||
| 锁模力 | Clamping force | kN | 7800 | |||
| 移模行程 | Open stroke | mm | 950 | |||
| 拉杆间距(宽×高) | Space between tie bars(W×H) | mm | 980×980 | |||
| 最大模厚 | Max.Mold height | mm | 960 | |||
| 最小模厚 | Min.Mold height | mm | 400 | |||
| 顶出行程 | Ejector stroke | mm | 280 | |||
| 顶出力 | Ejector stroke | kN | 210 | |||
| 其他 | OTHERS | |||||
| 最大油泵压力 | Max Pump pressure | kW | 16 | |||
| 油泵电机功率 | Pump motor power | kW | 37+37 | |||
| 电热功率 | Heating power | kW | 54.3 | |||
| 外形尺寸(长×宽×高) | Machine dimension(L×W×H) | m | 11.43×2.40×3.14 | |||
| 油箱容积 | Olitank cubage | L | 1200 | |||
| 机器重量 | Machine weight | t | 36 | |||
