| 项目 | Item | 单位 | N550 |
| 注射装置 | INJECTION UNIT | ||
| 螺杆直径 | Screw diameter | mm | 60 |
| 理论注射容量 | Shot volume(theoretical) | cm3 | 834 |
| 注射重量 | Injection weight(ps) | g | 759 |
| 注射速度 | Injection speed | mm/s | 359 |
| 注射速率 | Injection rate | g/s | 923 |
| 注射压力 | Injection pressure | Mpa | 185 |
| 螺杆转速 | Screw speed | rpm | 450 |
| 射移拉力（双射移） | Shooting force (double shooting) | kn | 110 |
| 注射行程 | Injection stroke | mm | 295 |
| 锁模装置 | CLAMPING UNIT | ||
| 锁模力 | Clamping force | kN | 5500 |
| 移模行程 | Open stroke | mm | 755 |
| 拉杆间距(宽×高) | Space between tie bars(W×H) | mm | 780*780 |
| 最大模厚 | Max.Mold height | mm | 850 |
| 最小模厚 | Min.Mold height | mm | 330 |
| 顶出行程 | Ejector stroke | mm | 202 |
| 顶出力 | Ejector stroke | kN | 110 |
| 其他 | OTHERS | ||
| 最大油泵压力 | Max Pump pressure | kW | 16 |
| 油泵电机功率 | Pump motor power | kW | 96 |
| 电热功率 | Heating power | kW | 28.4 |
| 外形尺寸(长×宽×高) | Machine dimension(L×W×H) | m | 8.9*2.2*2.3 |
| 油箱容积 | Olitank cubage | L | 700 |
| 机器重量 | Machine weight | t | 25 |
